Huatai small cooking oil refinery machine have won gold award on China Exhibition of Patents with the patent No. ZL99252888.7, which have many feature, such as light-weight, low electricity consumption, simple operation and saving investment. This small oil refining machine unit is suitable for the crude oil whose processing capacity is below 10T/D, such as crude soybean oil, rice bran oil, cottonseed oil, sesame oil, rapeseed oil, sunflower oil and peanut oil, etc.

Type: Small-size vegetable oil refining machine

Capacity: 1-10T/D

Processed Material: crude soybean oil, rice bran oil, cottonseed oil, sesame oil, rapeseed oil, sunflower oil and peanut oil, etc.

It is our patent product, which remove FFA from crude oil with the lowest oil loss.

This small oil refining machine is batch/intermittent refining equipment with all functions of large and medium-sized intermittent refining machine. It is a combination of complete refining machines equipped with heat source and electrical control. Customers only need turn on power, connect water and prepare little coal or firewood, caustic soda, phosphoric acid, bleaching clay etc., this small oil refining machine will come into operation.

The main equipment:

1) Neutralization pot: Use for acid refining, alkali refining and water washing.

2) Decolorization pot: Use to bleach oil and remove pigment.

3) Deodorization pot: Use to remove odors of oil (the material is stainless steel).

4) Heat conduction oil furnace: Provide heat energy for production, which temperature can reach 280℃.

5) Vacuum pump: Provide the needed vacuum degree of decolorization and deodorization, which up to above 755mgHg.

6) Air compressor: Dry bleaching clay.

7) Filter press: Filter bleaching clay.

Product Features:

1) It is for intermittent refining, and has all functions of large and medium-sized intermittent Oil Refining Equipment, also better than the large and medium-sized refining equipment;

2) Combined into whole set, it can provide heat source by itself with electric control, light weight and low power consumption;

3) It covers a small area, and easy to operate.
